3Ø - 3Ø Matrix Converter
3Ø - 3Ø Matrix Converter :
The 3Ø - 3Ø Matrix Converter is a cutting-edge power electronic device designed for efficient and reliable AC-to-AC conversion between three-phase systems. This converter enables direct energy transfer with high efficiency and low harmonic distortion, making it ideal for applications in industrial drives, renewable energy systems, and high-power machinery. With its advanced control capabilities and robust design, the matrix converter supports seamless integration into complex systems, offering superior performance and flexibility for engineers and designers seeking to optimize power conversion processes.
FEATURES :
- - 9 No. Bi-directional Switch with IGBT and Fast Diode Bridge,Rating@1200V 50A Forms 3 Phase to 3 phase Matrix Converter Power Circuit
- - Output of Matrix Converter Terminated by Banana Connector in the Front Panel.
- - 9 No. High Speed Opto- IC Provided for Gate PWM Isolation.
- - 9 No. Single Channel IGBT Driver IC with Current Limiting Facility Provided for IGBT Gate Driving.
- - 9 No. 15V DC Power Supply Provided Internally for Control Circuit.
- - 3 No. Inductor and AC Capacitor Provided for Three Phase Input Filter.
- - One No Three Phase Synchronizing Transformer (230/9V) Provided for three Phase Supply Synchronization
- - 6 nos Hall-effect Current Sensor with Signal Conditioning Circuit Provided for Output and Input Current Measurement and Protection.
- - AC voltmeter is provided for measure the input AC voltage
- +/- 15V DC Internally Provided for Sensor Signal Conditioner Circuits.
- - MCB Provided for Input power ON/OFF and OL Protection ON/OFF Switch.
- - Test points are provided on the front panel to measure the voltage, current and PWM signals
- - 34 pin FRC Connector Provided for IGBT Gate PWM Inputs.
- - Input : Three Phase 440V AC, 50 Hz.
- - Output : Three Phase Variable Voltage, variable frequency
- - Rating : Suitable for 1 HP 3Ø AC Induction Motor
